Stand on Electric Pallet Truck material handling equipment
65 Varyon Machinery
68 Varyon Machinery
67 Varyon Machinery
66 Varyon Machinery
Stand on Electric Pallet Truck material handling equipment
65 Varyon Machinery
68 Varyon Machinery
67 Varyon Machinery
66 Varyon Machinery

VY-CZB Stand on Electric Pallet Truck

Electric

Power Type

2000/2500/3000kg

Load Capacity

Standing-up

Driving Style
Load Centre: 600mm
Wheel Base: 1350mm
Self Weight: 550Kg

Features

The sine-wave vector controller provides smooth speed regulation and shock-free starting and stopping, protecting cargo. It also improves motor efficiency and saves energy.
It can maneuver flexibly through narrow aisles and between shelves, making it ideal for space-constrained environments such as warehouses and workshops.
The stand-up platform is designed with a well-designed operating handle that integrates all control functions, ensuring ergonomic operation and fatigue-free operation even after extended periods of operation.

Video

Specification

Lifting&Walking Electric Pallet Moverk(Stand-on Type)
Load Capacity2000kg2500kg3000kg
Power TypeElectricElectricElectric
Driving StyleStand-upStand-upStand-up
Loadcentre600mm600mm600mm
wheel base1350mm1350mm1350mm
Self weight550Kg550Kg550Kg
TyrePUPUPU
Drivewheel size(diameter*width)Φ250x80mmΦ250x80mmΦ250x80mm
Load Wheel size(diameter*width)Φ80x60mmΦ80x60mmΦ480x60mm
Balance wheel size (diameter*width)Φ100x50mmΦ100x50mmΦ100x50mm
Drive motor rating1.5KW1.5KW1.5KW
Lifting motor rating2.2KW2.2KW2.2KW

Request a Quote

官网询盘

Attachment

Side Shifter

Fork Positioner

Bale Clamp

Rotator

Roll Clamp

Carton Clamp

Carpet Pole

Push & Pull

Multiple Load Handler
